MikroTik KNOT Gateway HL9 - 915 MHz Wi-Fi HaLow, BLE & LTE IoT Gateway

MikroTik KNOT Gateway HL9 - 915 MHz Wi-Fi HaLow, BLE & LTE IoT Gateway

by MikroTik
SKU L14G-2ax-BT5-HL9&EG800Q
$202.00 - $202.00
$202.00
$202.00
$202.00 - $202.00
$202.00
+$19.49 Tariff Surcharge added at checkout. i Due to current Section 301 import tariffs and related surcharges, a fee applies to this product. This fee will be added at checkout.

Connectivity: 915 MHz Wi-Fi HaLow (HL9)

Product Information

Overview

The MikroTik KNOT Gateway connects sensors, Bluetooth tags, remote meters, and other IoT devices through a rugged IP66 platform. It combines Bluetooth Low Energy (BLE) 5.1, long-range sub-GHz connectivity, 2.4 GHz Wi-Fi, Gigabit Ethernet, LTE Cat 1 bis, and GNSS for deployments in warehouses, shipping terminals, industrial sites, and remote locations.

Choose the KNOT Gateway LR8 for 868 MHz LoRa connectivity or the KNOT Gateway HL9 for 915 MHz Wi-Fi HaLow. Both models provide Ethernet, Wi-Fi, and LTE backhaul options, allowing the gateway to operate close to the devices it serves, including locations without a wired internet connection.

RouterOS v7 supports local data filtering, scripting, and publishing information through MQTT or HTTP for integration with your preferred IoT platform. Integrated antennas, PoE-in, a separate DC power input, and external antenna connectors for BLE and sub-GHz connectivity provide installation flexibility.

Ideal Applications

  • Bluetooth asset tracking in warehouses and shipping terminals
  • Collecting telemetry from compatible industrial sensors
  • Remote meter monitoring through model-specific LoRa or Wi-Fi HaLow connectivity
  • IoT deployments using LTE backhaul where wired internet is unavailable
  • Local data filtering and forwarding to IoT platforms through MQTT or HTTP

Highlights

Key Features

Connect Sensors and Track Tagged Assets

Collect BLE 5.1 broadcasts from compatible tags and sensors to monitor telemetry and follow equipment, pallets, tools, and other assets as they move through your facility.

Extend Your IoT Reach

Choose 868 MHz LoRa on the LR8 model or 915 MHz Wi-Fi HaLow on the HL9 model to connect compatible devices beyond Bluetooth coverage.

Flexible Ethernet, Wi-Fi, and LTE Backhaul

Send collected data over Gigabit Ethernet, 2.4 GHz Wi-Fi, or LTE Cat 1 bis, with Nano SIM and eSIM support for flexible cellular connectivity.

Rugged Hardware with Local Processing

An IP66 enclosure, surge protection, and flexible power inputs support demanding installations, while RouterOS scripting, filtering, MQTT, and HTTP let you process and forward data locally.

Product Details

Technical Specifications

System Specifications

  • Product Name: MikroTik KNOT Gateway HL9
  • Product Code: L14G-2ax-BT5-HL9&EG800Q
  • CPU: Dual-core IPQ-5010, 800 MHz
  • CPU Architecture: ARM 64-bit
  • Memory: 256 MB DDR3L RAM
  • Storage: 128 MB NAND
  • Operating System: RouterOS v7
  • RouterOS License: Level 4

Ethernet and Wireless Connectivity

  • Ethernet Ports: 1 × Gigabit Ethernet port
  • Wi-Fi: 2.4 GHz 802.11b/g/n/ax
  • Wi-Fi Antenna Gain: 3.9 dBi
  • Bluetooth: BLE 5.1
  • Bluetooth Antenna Gain: 2.5 dBi
  • Wi-Fi HaLow Modem: FGH100MABMD
  • Wi-Fi HaLow Standard: IEEE 802.11ah
  • Wi-Fi HaLow Band: 915 MHz
  • Wi-Fi HaLow Antenna Gain: 5.4 dBi
  • External Antenna Connections: BLE and sub-GHz

Cellular and Positioning

  • LTE Modem: EG800Q-NA
  • LTE Category: Cat 1 bis
  • Maximum LTE Data Rates: 10 Mbps download / 5 Mbps upload
  • LTE FDD Bands: B2 (1900 MHz), B4 (1700 MHz), B5 (850 MHz), B12 (700 MHz), B13 (700 MHz), B66 (1700 MHz)
  • LTE MIMO: 1 × 1 downlink and uplink
  • SIM Slot: 1 × Nano SIM
  • eSIM: Supported, including MikroTik Connectivity
  • GNSS Module: AG3352Q, multi-GNSS positioning

Power

  • Number of DC Inputs: 2 (PoE-in and 2-pin terminal)
  • PoE-In: 802.3af/at
  • PoE Input Voltage: 18–57 V
  • 2-Pin Terminal Input Voltage: 12–57 V
  • Included Power Adapter: 24 V, 0.5 A
  • Maximum Power Consumption: 9 W
  • Surge Protection: Included

Physical and Environmental

  • Dimensions: 254 × 88 × 57 mm (10.00 × 3.46 × 2.24 inches)
  • Ingress Protection: IP66
  • Operating Temperature: -40°C to +50°C

In the Box

What’s Included

  • MikroTik KNOT Gateway in the selected model
  • 24 V 0.5 A power adapter
  • Gigabit PoE injector
  • Fastening set
  • Hose clamp

Resources

Product Documentation

Datasheet
