The Netonix WISP Switch model WS-6-MINI is designed specifically for the WISP industry with a rugged chassis and extended operating temperature range. It features a simple yet powerful user interface providing the software features WISPs need in a switch. Highest density of PASSIVE POE ports per cubic inch on the market for those small equipment boxes. The only switch line on the market that can deliver 1.5A of 24V or 48V on all 4 pairs (24VH and 48VH). The only switch line on the market that has current sensors on all passive POE ports. Port 1 will accept passive 48VH (48-56V) using all 4 pairs like a POE injector used to power an airFiber 24 GHz. If powering the WS-6-MINI with a 48-56V barrel connector power supply port 1 has no POE options, it is just a standard Ethernet port.

Manufacturer Warning:

Note: Prior to Rev F Port 2 used to support 24VH and 48VH only.

Note: Port 1 will accept passive 48VH (48-56V) using all 4 pairs like a POE injector used to power an airFiber 24 GHz. DO NOT power the WS-6-MINI with a standard passive POE adapter that only supplies 48V power on 2 pairs. If powering the WS-6-MINI with a barrel connector power supply be sure to connect the ground screw to Earth Ground for ESD protection.

Product Features

(5) Software selectable 1G POE ports
Manufactured and Assembled in North America
Standard Desktop / Wall mount
Dimensions 127mm x 118mm x 32mm
Operating temperature -25 to 55°C (-13 to 131° F)
Passive PoE current sensors on each port

Product Specifications

Manufactured and Assembled North America
Desktop / Wall mount YES
Dimensions 127mm x 118mm x 32mm
Weight 1 kg
Power Input 37-53 VDC
Chassis Earth Ground Lug YES
Max. Power Consumption 2A
Switch Core and PHYs Vitesse
Processor MIPS 24K 416 MHz
System Memory 128 MB
Flash Storage 16 MB
Total Non-Blocking Line Rate 6 Gbps
Certifications CE, FCC, IC
Operating Temperature -25 to 55°C (-13 to 131° F)
Operating Humidity 5 to 95% Non-Condensing
Ethernet Ports (6) 10/100/1000 Ethernet Ports
Passive PoE Configured Per Port via UI
24V 0.75A pins 4,5(+) 7,8(-)
48V 0.75A pins 4,5(+) 7,8(-)
24VH 1.5A pins 1,2,4,5(+) 3,6,7,8(-)
48VH 1.5A pins 1,2,4,5(+) 3,6,7,8(-)
PoE Out Voltage Range 48-50 VDC / 22-24 VDC
Passive PoE Current Sensors Per Port YES
ESD Rating 24 kV Air / 24 kV Contact

Product Includes
1 x Netonix WS-6-MINI 6-Port Switch

**Power Supply Not Included**
