Tycon Systems 8 Port 802.3af/Passive Gigabit PoE Midspan [TP-MS308]

Tycon Power POE 802.3af Gigabit Midspan Injectors, TP-MS308, is a rack mountable mid-span 802.3af (or passive) PoE injector. It has 8 ports, any of which can be configured for preferred method. The Tycon POE 802.3af Gigabit Midspan Injectors device features a separate data-in port coupled with a data out/POE port. The\ POE function is fully IEEE802.3af compliant. The included PC software allows for configuration of the individual ports and for displaying port status. Connecting to a PC is easy with the web interface. Ports can be configured for forced POE output (Passive POE) or IEE802.3af detection. POE DC Voltage (48V) is supplied on pins 4,5 (V+) and 7,8 (V-). Maximum power output per rack mount unit is 400W. The individual outputs are overload and short circuit protected. Product Features • IEEE 802.3af High Power Midspan POE Injectors • Up to 16.8W per Individual Port • 1U Standard Rack Mount (19”) • Configuration and status thru web interfacet • Supports Passive POE devices • Accepts AC or DC input • Remotely Power Multiple Equipment thru CAT5 Cable up to 100m Product Applications • Wireless Access Points and Client Devices • IP Phone and Security Camera Systems • Power Network Devices from a Central Network Room Product Specifications • Ethernet Standard: IEEE802.3 / IEEE803.3u / IEEE803.3ab (10base-T / 100base-T / 1000base-T) • PoE Standard: IEEE802.3af or 48VDC Passive PoE • Shielded RJ45 Ports: 8 data-in ; 8 data/PoE out • Console Port: RJ45 Management Port. Can also be managed via network • Max Device Distance: 100m (328ft) • Maximum PoE Power: 16.8W per Port, 350mA @ 48V • PoE Protection: Over Temperature, Over Current, Over/Under Voltage • AC Power Input: 100~240VAC, 50/60Hz • DC Power Input: -42 to -57VDC • Max Power Output: 134W • Operating Temperature: 0°C to 65°C (3°F to 149°F) • Operating Humidity: 10 to 95% (non condensing) • Storage Temperature: -20°C to 80°C (-4°F to 176°F) • Dimensions: 430 x 290 x 44mm (16.9 x 11.4 x 1.7") 1U rack mount 19" and 23" • Weight: 3.3kg (7lbs) Product Data Sheet Tycon Power Learning Center Presentation
