Tycon Systems 48VDC 802.3af/at PoE Input, 802.3af / 48V Passive PoE Output 32W Gigabit PoE Splitter [POE-SPLT-48G-VUB]
SKU POE-SPLT-48G-VUB
Original price
$121.00
Original price
$121.00
-
Original price
$121.00
Original price
$121.00
Current price
$121.00
$121.00
-
$121.00
Current price
$121.00
The POE-SPLT-48G-VUB is an active splitter which accepts an 802.3at Mode A/B or passive PoE (2 or 4 pair) input and provides two PoE outputs. Output 1 is an 802.3af Mode B PoE output with Data and PoE. Output 2 is a 48V Passive PoE Mode B output with PoE only, no data. The splitter is designed to supply power and data to one device and power only to the second device. It is Gigabit compatible providing speeds to 1000Mbps. There are various protections for short circuit, overload, and low voltage disconnect.
Product Features
- 802.3at PoE Input, 802.3af and Passive PoE Outputs
- Gigabit Compatible
- Extended Temperature Range: -40 to 70°C
- Short Circuit and Over Current Protection
