Tycon Systems 10-36VDC In 24V 4-Pair Out 24W Gigabit DC to DC Converter and PoE Inserter [TP-DCDC-1224G-4P]
SKU TP-DCDC-1224G-4P
Sold out
Original price
$135.00
Original price
$135.00
-
Original price
$135.00
Original price
$135.00
Current price
$135.00
$135.00
-
$135.00
Current price
$135.00
Tycon Power TP-DCDC-1224G-4P is a Gigabit DC to DC converter, with an output power of up to 24W. It features 4 pair Passive Power over Ethernet from a 12-24V source.TP-DCDC-1224G-4P is a low cost and high efficiency solution for those requiring 24VDC 4-pair Passive Power over Ethernet from a 12VDC or 24VDC voltage source like a battery or a system. It has an integrated 4 pair PoE injector to apply the power and data output to the CAT5 cable. It has two inputs for connecting 2 power sources, like a primary and backup source.
Product Features
- Input Voltage 9-36VDC
- 24V Gigabit Passive 4 Pair PoE Output
- Dual Inputs for Connecting 2 Power Sources
- Integrated 10/100/1000MB PoE Inserter
- High Power up to 24W
- Short Circuit, Over Current and Reverse/Over Voltage Protect
- High Temperature Operation to 70C
- Built-in Low Battery Disconnect and Surge Protection
- I.T.E. Power Supply, UL Listed
Applications
- 12V / 24V Battery Systems, Vehicle Applications
- UBNT Airfiber-X
- Wireless Access Points and Client Devices
