MikroTik mAP RBmAP2nD Mini 2.4GHz Wireless Access Point & Router with PoE

MikroTik mAP RBmAP2nD Mini 2.4GHz Wireless Access Point & Router with PoE

by MikroTik
SKU RBmAP2nD
$65.00 - $65.00
$65.00
$65.00
$65.00 - $65.00
$65.00
+$5.98 Tariff Surcharge added at checkout. i Due to current Section 301 import tariffs and related surcharges, a fee applies to this product. This fee will be added at checkout.

Product Information

Overview

The MikroTik mAP RBmAP2nD is an ultra-compact 2.4 GHz wireless access point and router designed for portable networking applications. Measuring just 68 × 68 × 19 mm, it combines 802.11b/g/n wireless connectivity, two 10/100 Mbps Ethernet ports, and MikroTik RouterOS capabilities in a small, lightweight form factor.

The mAP supports both wireless access point and station modes, making it suitable for temporary wireless networks, portable access point deployments, and connecting wired devices to wireless networks. Flexible power options include microUSB, a power jack, and passive or 802.3af/at PoE input.

In addition to providing wireless connectivity, the second Ethernet port supports passive PoE output of up to 500 mA for powering a compatible device. The microUSB interface can also connect a compatible external 3G/4G modem, allowing the mAP to serve as a portable cellular hotspot when paired with additional hardware.

Ideal Applications

  • Portable Wireless Access Point
  • Small Network Routing
  • Temporary Wireless Network Deployments
  • Wireless Station Connectivity
  • Passive PoE Device Powering
  • 3G/4G Hotspot with Compatible USB Modem

Highlights

Key Features

Ultra-Compact Wireless Router

Measuring just 68 × 68 × 19 mm, the mAP combines 2.4 GHz 802.11b/g/n wireless connectivity and RouterOS functionality in a compact design for portable networking.

Flexible USB & PoE Power Options

Supports power through microUSB, a power jack, passive PoE (10–57V), or 802.3af/at PoE input, allowing the device to operate with different available power sources.

Passive PoE Output on Ether2

The second Ethernet port provides passive PoE output of up to 500 mA, allowing the mAP to power compatible network equipment such as a MikroTik SXT CPE device.

Access Point, Station & USB Modem Support

Supports wireless access point and station modes, while the microUSB interface can connect a compatible external 3G/4G modem for cellular hotspot applications.

Product Details

Technical Specifications

System Specifications

  • Product Code: RBmAP2nD
  • CPU: Qualcomm Atheros AR9531, 650 MHz
  • Memory: 64 MB DDR2 RAM
  • Storage: 16 MB Flash
  • Operating System: MikroTik RouterOS v6
  • License Level: 4

Wireless & Networking

  • Wireless Chipset: QCA9531
  • Wireless Frequency: 2.4 GHz
  • Wireless Standards: 802.11b/g/n
  • Built-In Antenna: 1.2 dBi
  • Wireless Modes: Access Point / Station
  • Ethernet: 2 × 10/100 Mbps Ports with Auto-MDI/X
  • USB Interface: microUSB

Power Specifications

  • Power Input: Passive PoE, 802.3af/at PoE, USB, or Power Jack
  • Passive PoE Input Voltage: 10–57 V
  • Passive PoE Output: Ether2
  • Maximum PoE Output Current: 500 mA
  • PoE Output Voltage: Same as Input Voltage
  • Included Power Adapter: 24 V, 0.8 A

Physical & Environmental

  • Dimensions: 68 × 68 × 19 mm
  • Operating Temperature: -20°C to +70°C



In the Box

What’s Included

  • MikroTik mAP RBmAP2nD Wireless Access Point
  • 24 V 0.8 A Power Adapter
  • microUSB Type-B to USB Type-A Adapter
  • K-33 Mounting Kit



Resources

Product Documentation

Datasheet
