MikroTik CRS504 4x QSFP28 100Gbps Cloud Router Switch [CRS504-4XQ-IN]

CRS504-4XQ-IN by MikroTik
Save 16% Save 16%
Original price $1,113.00
Original price $1,113.00 - Original price $1,113.00
Original price $1,113.00
Current price $936.00
$936.00 - $936.00
Current price $936.00

There are four 100 Gigabit QSFP28 ports. Use them to connect other 100 Gigabit devices or grab a breakout cable to connect multiple 25 Gigabit devices: each port is connected to four 25 Gigabit lines, allowing you to connect 16 x 25 Gigabit devices. In fact, you can mix and match all kinds of connections this way: 100 Gigabits on one port, 40 Gigabits on the other, 4x25 Gigabits on the third, and maybe even some 10G or 1G cables on the fourth. Obviously, there is an Ethernet port for management purposes as well.

We’ve been using this switch for quite some time now in the Genomics Data Network project. A high-capacity data network for our local scientists working on ground-breaking cancer treatments. Genome data can take up a lot of space, so you need exceptionally fast connections there. Also, with these devices, Latvia became the first Baltic country to establish a 100 Gigabit connection to the pan-European research network.

Product Features:
  • 4x QSFP28 100Gbps ports
  • 1x RJ45 console port, 1x Fast Ethernet 10/100 Mb/s port for PoE-in management
  • Power supply via: PoE-in 43-57 V, DC input 36-57 V, 2-pin terminal 36-57 V
  • Compatible with 40G, 25G, 10G, 1G fiber optic connections
  • 2x Hot swap power supplies
  • RouterOS Level 5 license
Product Specifications:
  • Processor: QCA9531, 650MHz
  • Number of cores: 1
  • Architecture: MIPSBE
  • Built-in memory: Flash 16MB
  • RAM: 64MB
  • Interfaces: 4x 100Gb / s QSFP28, 1x Fast Ethernet 10 / 100Mb / s PoE-in, port 1x serial RJ45 port
  • Switch chip: 98DX4310
  • Dimensions: 12.59" x 7.28" x 1.73" (320mm x 185mm x 44mm)
  • Operating system: RouterOS v7 license Level 5
  • Permissible operating temperature: -40°F to 158°F (-40°C to 70°C)
  • Power methods: (PoE-in, DC jack, 2-pin terminal)
  • PoE-in voltage range: 43V - 57V
  • DC input voltage range: 36V - 57V
  • 2-pin terminal voltage range: 36V - 57V
  • Maximum power consumption: 41W
  • Power consumption without PoE: 25 watts
Product Includes:
(1) MikroTik CRS504 Cloud Router Switch
(2) Power Cords
(1) Fastening Set
(1) Rack Ears
