Cambium PTP 820 3' Single Polarization Dish Antenna, 11GHz, RFU-C [N110082D073A]

N110082D073A by Cambium Networks
Sold out
Original price $2,630.00 - Original price $2,630.00
Original price $2,630.00
$2,630.00
$2,630.00 - $2,630.00
Current price $2,630.00

The Cambium PTP 820 3' Single Polarization Dish Antenna, 11GHz, RFU-C features Standard Interface UBR100 - Andrew. This antennas is designed to work with Cambium PTP 820 radios.

Product Specifications:

  • Diameter (nominal): 1.0 m / 3 ft
  • Polarization: Single
  • Beamwidth (horizontal): 2.0°
  • Beamwidth (vertical): 2.0°
  • Cross Polarization Discrimination (XPD): 30 dB
  • Front-to-Back Ratio: 64 dB
  • Gain, Low Band: 37.2 dBi
  • Gain, Mid Band: 38.4 dBi
  • Gain, Top Band: 39.0 dBi
  • Operating Frequency Band: 10.125 - 11.700 GHz
  • Radiation Pattern Envelope Reference (RPE): 7164 | 7166
  • Return Loss: 17.7 dB
  • VSWR
Mechanical Specifications:
  • Fine Azimuth Adjustment: ±15°
  • Fine Elevation Adjustment: ±15°
  • Mounting Pipe Diameter: 115 mm | 4.5 in
  • Net Weight: 24 kg | 53 lbs
  • Wind Velocity Operational: 200 km/h | 124 mph
  • Wind Velocity Survival Rating: 250 km/h | 155 mph
Wind Forces at Wind Velocity Survival Rating:
  • Angle a for MT Max: 0°
  • Axial Force (FA): 2979 N | 670 lbf
  • Side Force (FS): 936 N | 210 ibf
  • Twisting Moment (MT): 1184 N•m
  • Weight with 1/2 in (12 mm) Radial Ice: 46 kg | 101 lb
  • Zcg with 1/2 in (12 mm) Radial Ice: 220 mm | 9 in
  • Zcg without Ice: 324 mm | 13 in
