Ubiquiti UniFi 6 Access Point Wi-Fi 6 Long-Range 5GHz 3 Gbps 4x4 MU-MIMO

U6-LR-US by Ubiquiti Networks
Sold out
Original price $189.00 - Original price $189.00
Original price
$189.00
$189.00 - $189.00
Current price $189.00

The Ubiquiti UniFi 6 Long-Range Access Point delivers an aggregate radio rate of up to 3.0 Gbps with 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz 4x4 MIMO radios. The Ubiquiti U6-LR seamlessly blends into any environment, and is capable of being mounted in indoor and semi-outdoor environments (IP54 rated), and comes equipped with a Bluetooth Low Energy Radio for location based services.


Product Features:
  • 1.3GHz dual-core processor (now upgraded to support full-duplex 1Gbps TCP/IP performance)
  • Four-stream high-efficiency Wi-Fi 6 technology
  • 5GHz band 4x4 MU-MIMO and OFDMA with radio rate of 2.4Gbps
  • 2.4GHz band 4x4 MIMO with radio rate of 600Mbps
  • Powered with 802.3at PoE (PoE injector not included)
  • Enclosure Material: Plastic
  • Mounting Material: SGCC Steel
  • Weatherproofing: IP54
  • Wi-Fi Standards:
  • 802.11a/b/g
  • Wi-Fi 4/ Wi-Fi 5/ Wi-Fi 6
  • Wireless Security: WPA-PSK, WPA-Enterprise
Product Specifications:
  • Processor Specs: Dual-Core Cortex A53 at 1.35GHz
  • Memory Information: 512 MB
  • Management Interface: Ethernet
  • Networking Interface: (1) 1 Gbps Ethernet RJ45
  • Button: Factory Reset
  • LEDs: RGB
  • Power Method: PoE+, Passive PoE (48V)
  • Power Supply:
          UniFi PoE Switch
          48V, 0.5A PoE Adapter (Not Included)
  • Supported Voltage Range: 44 to 57VDC
  • Max. Power Consumption: 16.5W
  • Max. TX Power:
          2.4GHz: 26dBm
          5GHz: 26dBm
  • MIMO:
          2.4GHz: 4x4
          5GHz: 4x4
  • Throughput Speeds:
          2.4GHz: 600Mbps
          5GHz: 2400Mbps
  • Antenna Gain:
          2.4GHz: 4dBi
          5GHz: 5.5dBi
  • Mounting: Wall/Ceiling (Kits Included)
  • Operating Temperature: -30 to 60° C (-22 to 140° F)
  • Operating Humidity: 5 - 95% Non-condensing
  • Certifications: CE, FCC, IC
Product Includes:


(1) U6 Access point

(1) Wall mounting kit

(1) Ceiling mounting kit

(2) Allen wrenches
