Tycon Power 18-36VDC Input, 56VDC 1.25A 70W Output Voltage Converter

TP-VRHP-2456 by TYCON Systems
Sold out
Original price $95.95 - Original price $95.95
Original price
$95.95
$95.95 - $95.95
Current price $95.95
The TP-VRHP-2456 is a 70W voltage converter/regulator which accepts an input of plus or minus 18VDC to 36VDC and provides a regulated output of 56VDC @ 1.25A 70W. These units are perfect for providing 56VDC voltage from 24VDC battery banks. Product Features • High Output, Short Circuit Protected • Metal Enclosure, DIN Rail Mounting • Industrial Temperature Operation Product Applications • Security Systems • Remote Power Systems • Telecom Applications • Wireless Base Stations Product Specifications • DC Input Voltage Range: 18 to 36VDC • DC Voltage Output: 56VDC @ 1.07A • Maximum Power: 60W • Efficiency: >85% • Load / Line Regulation: 5% / 1% • Ripple / Noise: 2% / 5% • Isolation Voltage / Ohms: 1500VDC Min. / 100M Ohms Min • Wire Gauge: 12AWG Max • Protections: Short Circuit, Overvoltage, Overload • Operating Humidity: 0 to 90% RH • Size: 5.24 x 3 x 1.5" (133 x 75 x 38mm) • Weight: 10.5oz (298g) Product Documentation TP-VRHP-2456 Datasheet Tycon Power Learning Center Presentation
