Tycon Power 18-36VDC Input, 24VDC 2.9A 70W Output Voltage Converter
TP-VRHP-2424
by TYCON Systems
Sold out
Original price
$54.95
-
Original price
$54.95
Original price
$54.95
$54.95
-
$54.95
Current price
$54.95
The TP-VRHP-2424 is a 70W voltage converter/regulator which accepts an input of plus or minus 18VDC to 36VDC and provides a regulated output of 24VDC @ 2.9A 70W. These units are perfect for providing stable regulated 24VDC voltage from 24VDC battery banks.
Product Features
• High Output, Short Circuit Protected
• Metal Enclosure, DIN Rail Mounting
• Industrial Temperature Operation
Product Applications
• Security Systems
• Remote Power Systems
• Telecom Applications
• Wireless Base Stations
Product Specifications
• DC Input Voltage Range: 18 to 36VDC
• DC Voltage Output: 24VDC @ 2.5A
• Maximum Power: 60W
• Efficiency: >85%
• Load / Line Regulation: 5% / 1%
• Ripple / Noise: 2% / 5%
• Isolation Voltage / Ohms: 1500VDC Min. / 100M Ohms Min
• Wire Gauge: 12AWG Max
• Protections: Short Circuit, Overvoltage, Overload
• Operating Humidity: 0 to 90% RH
• Size: 5.9 x 7.4 x 1.7" (150 x 187 x 43.6mm)
• Weight: 2.6lbs (1.2kg)
Product Documentation
TP-VRHP-2424 Datasheet
Tycon Power Learning Center Presentation
