Tycon Power 10-15VDC In, 24VDC Out 35W Hi Power DC to DC Converter and POE inserter

TP-DCDC-1224-HP by TYCON Systems
Original price $57.95 - Original price $57.95
Original price
$57.95
$57.95 - $57.95
Current price $57.95
Product Features
  • Input Voltage 12VDC
  • Passive PoE Output Voltage 24VDC
  • High Power up to 35W
  • Integrated PoE Inserter
  • Low Self Consumption
  • Short Circuit, Over Current and Reverse/Over Voltage Protection
  • High Temperature Operation
Product Applications
  • 12V, 24V and 48V Battery Systems
  • Wireless Access Points and Client Devices
  • IP Phone and Security Camera Systems
Product Specifications
  • Input Voltage: ± 10VDC to 15VDC
  • DC Input Connector: Removeable Screw Type Compression Wire Terminal (12 AWG Max)
  • PoE Specification: Passive
  • Output Voltage (±2/5%): 24VDC
  • Data In & Data/PoE Output Connector: RJ45 (Shielded)
  • Output Current (max): 1.46A
  • Output Power (max): 35W
  • Self Consumption Power: 2W
  • Efficiency (min): 75%
  • Line Regulation: 1%
  • Load Regulation: 5%
  • Ripple: 1%
  • Noise: 1%
  • EMC Standards: FCC Class B NE55022 Class B
  • Safety Standards: UL1950, CSA 22.2 &TUV EN60950
  • Operating Temperature: -30 to 60°C (-22 to 140°F)
  • Operating Humidity: 5% to 90%
  • Storage Temperature: -40 to 80°C (-40 to 176°F)
  • Dimensions: 125 x 75 x 38 mm (4.9 x 3 x 1.5 ")
  • Weight: 300g (10.6oz)
