MikroTik OmniTik 5 ac 5GHz 802.11ac 2.5 dBi Gigabit Access Point w/ PoE Output INTL

RBOmniTikPG-5HacD by MikroTik
Sold out
Original price $123.95 - Original price $123.95
Original price
$123.95
$123.95 - $123.95
Current price $123.95

OmniTIK 5 PoE ac (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).


OmniTik 5 ac features five Gigabit Ethernet ports and support for 802.11ac. It's equipped with a powerful 720MHz CPU, 128MB RAM, high power 1300mW 802.11a/n/ac Dual Chain wireless (support for AC as well as backwards compatible with regular 802.11a/n CPE) and comes with a newly designed weatherproof enclosure, two integrated 7.5dBi 5GHz omni antennas, a power supply, a PoE injector and a mounting kit. This PoE version also supports passive or standard 802.3at/af PoE input/output (12v-57v). Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. It can power 48V devices (like IP cameras), if 48V input is used.


Product Specifications:

  • CPU: QCA9557 720 MHz
  • Memory: 128 MB
  • Storage Type: Flash
  • Storage Size: 16 MB
  • Ethernet: Five 10/100/1000 Mbits/s Fast Ethernet port with Auto-MDI/X
  • Wireless: QCA9892, wireless built-in 5 GHz 802.11ac, dual chain
  • Frequency Range: 5150 - 5875 MHz
  • Power Options: PoE input, passive 12-57 V
  • PoE Out: Yes, Ether2 - Ether5
  • Max Output per Port: 1A (if input < 30 V) / 0.5A (if input > 30 V)
  • Consumption: 18 W
  • Antenna Gain: 7.5 dBi
  • Antenna Beam Width: 360°
  • USB: 1 x USB type A
  • Dimensions: 416 x 129 x 58 mm
  • Operating Temperature: -40 to 70°C tested
  • LEDs: 10x LEDs
  • License Level: 4
  • Operating System: RouterOS
Product Includes:
  • 1 x MikroTik OmniTik 5 GHz ac AP w/ PoE
  • 1 x 28V 2.57A Adapter
  • 1 x Pole Mount Bracket
  • 1 x Metal Ring
  • 1 x Gigabit PoE Injector
  • 1 x IEC Cord
Product Documentation:


RBOmniTikPG-5HacD Datasheet
