MikroTik hEX S 5 Gigabit Port Dual-Core 880MHz Ethernet Router w/SFP Level 4

MikroTik hEX S 5 Gigabit Port Dual-Core 880MHz Ethernet Router w/SFP Level 4

RB760iGS by MikroTik
Sold out
$66.95 - $66.95
$66.95
$66.95 - $66.95
$66.95

MikroTik hEX S comes with a very powerful dual core 880MHz CPU and 256MB RAM, capable of all the advanced configurations that RouterOS supports. The device has a USB 2.0, PoE output for Ethernet port #5 and a 1.25Gbps SFP cage. IPsec hardware encryption (~470Mbps) and the MikroTik The Dude server package is supported, microSD slot on it provides improved r/w speed for file storage and Dude.


Product Specifications
  • Product code: hEX S
  • CPU: MT7621A
  • CPU nominal frequency: 880MHz
  • CPU core count: 2
  • CPU threads: 4
  • Size of RAM: 256MB
  • 10/100/1000 Ethernet ports: 5
  • SFP cages: 1
  • PoE in: Passive, 802.3af/at
  • PoE out: Passive PoE up to 57 V (Ether5)
  • Supported input voltage: DC and PoE in: 12 - 57 V
  • Power output:
        Max out per port output (input < 30 V): 500mA
        Max out per port output (input > 30 V): 500mA
        Max total out: 500 mA
  • PCB temperature monitor: Yes
  • Voltage monitor: Yes
  • USB slot: USB type A
  • MicroSD slot: 1
  • Operating temperature: -40° to 158°F (-40°C to +70°C)
  • Dimensions:
  • License level: 4
  • Operating System: RouterOS
  • Max Power consumption: 11 W
Product Includes


(1) MikroTik hEX S Router
(1) Power Adapter (24V 1.2 A)
(1) User Guide


Product Documentation


MikroTik hEX S Data Sheet
