Maxxwave Routermaxx Vengeance MINI 6-Port gBe 4-Port SFP+ Router (Complete Solution)

MW-RM-Vengeance-MINI by Maxxwave
Sold out
Original price $2,119.99 - Original price $2,119.99
Original price $2,119.99
$2,119.99
$2,119.99 - $2,119.99
Current price $2,119.99

The Maxxwave Routermaxx Vengeance MINI 6-Port gBe 4-Port SFP+ Router is custom-built by Maxxwave. This high speed gigabit router is built for performance and is based on industrial strength hardware. By using the Intel 6 Core C3758 Denverton Processor technology, we are able to deliver a next-generation router. Easy setup allows you to plug it in and start configuring. The Vengeance Mini comes with a VMware ESXI 7.0 and Linux. You may also use a Vengeance Mini to run virtual machines such as Ubuntu, or the Ubiquiti UniFi Controller. A simple set up allows you to plug the router in and start configuring. The power of a Maxxwave Routermaxx Vengeance in a smaller package!

Product Features
  • Intel Atom processor C3758 (Denverton)
  • (4) DDR4 R-DIMM for up to 128GB of memory or U-DIMM for up to 64GB of memory
  • (6) 10/100/1000 Mbps Ethernet ports and four SFP+ ports
  • Wi-Fi/3G/LTE through PCI Express Mini Card slot for optional
  • Supports Intel QuickAssist Technology
  • Suitable for Edge Routing, Virtualization, and LTE Gateway
  • Form Factor: 1U desktop
  • LED: Power, HDD, GPIO programmable, LAN Bypass, Link/Act with transfer rate
  • Operating Temperature 0°C to +40°C (+32°F to +104°F)
  • Humidity 10% - 95% RH, non-condensing
  • Chassis Material: Steel
  • Certifications: FCC class B/CE class B
Product Specifications
  • CPU: Intel Atom processor C3758 (Denverton)
  • Chipset: SoC integrated
  • Memory: (4) DDR4 R-DIMM, up to 128GB/U-DIMM, up to 64GB non-buffer non-ECC/ECC memory
  • BIOS: AMI SPI Flash BIOS
  • Storage:
    (1) 2.5" SATA3 HDD
    (1) mSATA
  • Network Interface:
    (6) 10/100/1000 Mbps Ethernet (Intel i210)
    (4) 10GbE SFP+
  • I/O:
    (1) RS-232 (RJ-type)
    (2) USB 2.0
    (6) RJ-45
    (4) SFP+
  • Other Features: LAN Bypass function through latch relay (one pair) for optional
  • Expansion Interface: (1) PCI Express Mini Card slot (PCIe interface)
  • Watchdog Timer:
    255 stepping for system reset
    8 stepping for LAN Bypass
  • Power Supply: (1) 12V, 7A power adapter
  • OS Compatibility: Linux. ESXI 7.0
Product Includes
(1) DC Power Adapter (12V/7A)
(1) Power Cord
(1) SATA Cable
