Cambium PTP 820 2' Single Polarization Dish Antenna, 11GHz, RFU-C [N110082D072A]

N110082D072A by Cambium Networks
Sold out
Original price $779.63 - Original price $779.63
Original price $779.63
$779.63
$779.63 - $779.63
Current price $779.63



Cambium PTP 820 2' ANT SP 11GHz RFU-C Type & Standard UBR100 - Andrew

Product Specifications:

  • Alpha frequency 11 GHz
  • Front-to-back ratio (dB) 60 dB
  • Mounting hardware included (Y/N) Y
  • Maximum power input (W) 150W
  • Polarization: horizontal or vertical
  • Lightning protection: DC ground
  • Vertical tilt (deg): 0 deg
  • Antenna Diameter (ft): 2'
  • Radome (Y/N): Y
  • Antenna size range: 2 ft to 3 ft
  • Frequency range: 10500-11650
  • dB gain range: 30.0 to 39.9
  • Gain: 4.5 dBi
  • Frequency (bandwidth): 10.7-11.7 GHz
  • VSWR <1.30:1
  • Connector: RFU-C type & standard UBR100
  • Wind survival w/o ice (MPH): 155 MPH
  • Beam width (deg): 3.3 dB
  • Depth: 27.8"
  • Width: 31.4"
  • Height: 13"
  • Weight: 35.3 LB
