Cambium cnPilot Enterprise E502S Outdoor 2.4/5GHz Access Point 30 degree Integrated Sector Antenna and Tilt Bracket PoE Injector

PL-502SP00A-US by Cambium Networks
Sold out
Original price $603.75 - Original price $603.75
Original price
$603.75
$603.75 - $603.75
Current price $603.75

Cambium cnPilot Enterprise E502S is a cnPilot outdoor sector access point with 30 degree Integrated Sector Antenna and Tilt Bracket PoE Injector. The 802.11ac e502S is the essential workhorse for today’s demanding high density outdoor Wi-Fi networks.


Product Features:

  • Supports 256 clients, 16 SSIDs, WPA-2 encryption, Dynamic VLANs, DFS channels, Access Control Lists (ACL), and more
  • Rapidly setup multi-hop mesh networks by either dedicating one radio for mesh backhaul, or using both bands for client access simultaneously
  • Aux PoE port offers PoE out, perfect for powering a standard 802.3af camera or Cambium's PMP 450 or ePMP backhaul SMs
  • Dual on-board Active/Standby memory banks ensure higher availability. Can store two versions of the software
Product Specifications:
  • Frequency Bands: 2.4GHz: 2.4 - 2.4835GHz, Channels 1 - 13 (ETSI/CE), Channels 1 -11 (US), 5GHz: 5.15 - 5.85GHz
  • SSID Security: WPA-2 (802.11i): WPA2-Enterprise (802.1x/EAP) and WPA2-Preshared-keys, Open
  • Max SSID: 16
  • Max Concurrent Clients: 256
  • Max Range: Client: 213m (700ft); Actual range will vary based on local RF conditions and client capability, Mesh: 2.4GHz: 3000m (9840ft), 5GHz: 1500m (4900ft)
  • Max Data Rates: 1.01Gbps
  • Ethernet Ports: Dial Gigabit Ethernet ports
  • Antenna: Dual polarized. 2x2 MIMO. Integrated Sector antenna
  • Antenna Gain: 2.4GHz: 10.5dBi, 5GHz: 13dBi
  • Power Supply: 56V/30W Gigabit passive PoE injector
  • PoE Out: Aux port: capable of 802.3af power out or canopy power
  • Transmit Power: 2.4GHz: 29dBm, 5GHz: 28dBm
  • Power Consumed: Typical: 8W, Max: 12.95W
  • Dimensions: 30 x 20.4 x 6.5cm (without bracket)
  • Weight: Without Bracket: 881g, With Bracket: 1063g
  • Operating Temperature: -30 to 60°C
  • Mounting Options: Pole mount bracket (included) or wall-mount (with included bracket or without)
  • LTE Co-Existence: Special filter for rejecting interference on 2.4GHz from adjacent LTE bands 38, 40
  • Physical Security: Kensington Lock Bracket
  • Visual Status: (2) multi-color LEDs indicating Access Point and cnMaestro connectivity status

Product Includes:

(1) cnPilot E502S Access Point

(1) User Guide
