Primus Cable's Dual Shielded Outdoor Direct Burial CAT6 Cable is ideal for your outdoor voice, data, video and security networking applications. Whether you are wiring your home, office or entire campus, we have the network solution that is right for you.

This Dual Shielded Outdoor Direct Burial CAT6 Enhanced Cable is the perfect fit for installations where the cable will be buried under ground in conduit. This cable's 8 conductors (4-Pairs) are solid bare copper with a high density polyethylene (HDPE) insulation and a low density polyethylene (LDPE) Jacket. This cable also includes a dual shielding which helps eliminate electrical interferences that could impede your signal. This dual shielding is comprised of aluminum shielding and then wrapped in braided aluminum which offers to layers of protection from interference. Additionally, this cable has a tinned copper drain wire which grounds the electricity after it has been terminated. This drain wire is required on all shielded cable in order to prevent signal loss, cross-talk, and other performance issues. The Category 6 Direct Burial Outdoor Cable is designed for residential outdoor direct burial LAN applications, making it the ideal solution for installation runs that require the cable to be buried under ground in conduit. This cable is also tested up to speeds of 600MHz.

To make sure they are supplying customers with high quality bulk Ethernet cables these cables have to meet and/or exceed CAT6 ANSI/TIA-568.2-D standards. Primus Cable's CAT6 Outdoor cable is also manufactured to meet current CAT6 guidelines and is verified by outside standards organizations and is RoHS Compliant.

Product Applications

NTSC/PAL Component or Composite Video
AES/EBU Digital Audio
Other high-performance applications:
• Noisy Environments
• Harsh Environments
• Direct Burial
• Industrial Ethernet

Product Features

High-Performance Data Communications Cable
CAT6 Outdoor Direct Burial, UV Rated, Outside Plant
Suitable For 600MHz High-Speed Data Applications, Gigabit Ethernet, Fast Ethernet And 155Mbps TP-PMD/CDDI
Designed For Outdoor Installations
TC Braided + AL Foil Shielded w/ Unshielded Twisted Pairs (SF/UTP)
4-Pair Easily Identified Color Striped Pairs
23 AWG Solid Bare Copper Conductors
Excellent Attenuation And Crosstalk Characteristics
Exceeds TIA 568C.2, ISO/IEC 11801, And YD/T1019 Specifications
RoHS Compliant
Sequential Length Markings On Jacket
Supplied On A 1000' Wooden Spool In A Box

Product Specifications:
Physical:

Size: 15”x15”x13”
Resolution: 3.2μm
Conductor Size: 23AWG
Conductor Material: Solid Bare Copper
Insulation Material: High Density Polyethylene (HDPE)
Insulation Diameter: 1.12 ± 0.05mm
Number of Conductors: 8 Conductors
Number of Pairs: 4 Pairs
Outer Shield Material: Aluminum Foil
Braid Shielding: Tinned Copper 0.10mm
Drain Wire: Yes
Outer Jacket Material: LDPE (Complies RoHS)
Outer Jacket Diameter: 7.8mm ± 0.4mm
Outer Jacket Rip Cord: Yes

Mechanical:

Storage Temperature Range: N/A
Installation Temperature Range: N/A
Operating Temperature Range: N/A
Bulk Cable Weight: 42lbs. / 1000FT
Max. Recommended Pulling Tension: N/A
Min. Bend Radius/Minor Axis: N/A
Min. Bend/Installation: N/A
Test Object: Jacket
Test Material: PVC
Before Tensile Strength: ≥10.0
• Aging Elongation: ≥350
• Aging Condition: 100°C x 24hrs x 10Days
After Tensile Strength: N/A
• Aging Elongation: ≥300
• Cold Bend: No Visible Cracks (-20°C ± 2°C x 4h)

Package Contents:

(1) Primus Cable CAT6 Bulk Double Shielded Tinned Copper 23AWG Cable
(1) Black Jacket
(1) 1000ft On A Wooden Spool In A box
