Designed to allow users to customize their solution according to their specific communication needs, the Grandstream GVC3210 can be paired with most video and web conferencing services to create a multi-point conferencing system. This video conferencing endpoint runs on the Android operating system and offers full access to the Google Play Store. This allows users to utilize any Android conferencing or communication application. The GVC3210 comes equipped with sophisticated Noise-Shield technology to block out background noise and maximize audio quality. Additional features include advanced 4-microphone array with beam-forming capability, a high-end 16M pixel CMOS sensor with ePTZ for easy camera view adjustments and Miracast wireless for convenient content sharing. This simple yet powerful video conferencing endpoint is the ideal choice for SMBs looking for a price-friendly option that still carries the high-end features needed to sustain high-quality business communications.

Product Features:

Sharp HD video resolutions up to 4k Ultra HD
Runs on Android 6.x operating system with full access to applications in the Google Play store
Built-in Bluetooth for use with Bluetooth speakers/ microphones, keyboards, data exchange, etc.
Integrated dual band WiFi to pair with video and web conferencing service
Built-in 4-MIC array with beam-forming, support for external audio equipment and innovative Noise Shield technology
Advanced camera with 16M pixel CMOS sensor, 90 FOV wide angle lens and ePTZ for easy camera view adjustments
Support for Miracast wireless content sharing to share a presentation with conference attendees
Integrated 1x HDMI in, 2x HDMI out, and 2x USB

Product Specifications:

Protocols / Standards SIP RFC3261, BFCP, TIP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, LLDP-MED, LDAP, TR-069 (pending), 802.1x, TLS, SRTP, TCP/IP/UDP, IPv6, H.323
Camera: 1/2.3“, 16 Megapixel CMOS, 4K (2160p) Output
Lens: 90°field of view, ePTZ (3x digital zoom)
Network Interface: (1) RJ4510/ 100/ 1000 Mbps
WiFi: Integrated dual-band 802.11 a/b/g/n/ac (2.4GHz & 5GHz)
Bluetooth: Integrated Bluetooth 4.0 + EDR
Video Outputs: (2) HDMI 1.4 up to 4K (2160p) with CEC
Video Input: (1) HDMI 1.4 with resolution up to 1080p
MIC/Speaker: Built-in (4) MIC array
Remote Control: Bluetooth and infrared remote control with multi-touch touchpad
Auxiliary Ports: (2) USB 2.0, micro-SD, Reset
Voice Codecs: Support for G.711μ/a, G.722 (wide-band), iLBC, Opus , G.722.1, G.722.1c ,G729A/B, in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO)
Video Codecs: H.264 BP/MP/HP, video resolution up to 4K (2160p), frame rate up to 30 fps, bitrate up to 16Mbps
Video Resolutions: 4K (2160p@30fps) from 4096Kbps, 1080p@30fps from 1024Kbps, 720p@30fps from 512 Kbps, 4SIF/4CIF from 128 Kbps, SIF/CIF from 64 Kbps
Content Resolutions Input: VGA, SVGA, XGA, 1280×600, WXGA, WXGA, SXGA, 1440×900, XGA+, 720p, 1600×1200, 1080p (HDMI), up to 60fps
Content Resolutions Encoding: 800×600, 1024×768, 1280×1024, 1280×720, 1920×1080
Content Resolutions Output: 720p, 1080p
Dual-Stream: BFCP, video resolution (up to 4K 2160p@30fps) + content resolution (up to 1080p@15fps)
Audio Features: AEC, ANS, AGC, Noise Shield, PLC, CNG/VAD
Video Features: FEC, dynamic display layout, picture-in-picture, picture-outside-picture, digital caption
Telephony Features: Hold, forward (unconditional/no-answer/busy), downloadable phone book (XML, LDAP), call waiting, call history, flexible dial plan, personalized music ringtones, server redundancy & fail-over
Sample Applications: Skype, Google Hangouts, Microsoft Lync, Web browser, Adobe Flash, Facebook, Twitter, YouTube, Google calendar, mobile phone data import/export via Bluetooth, etc. API/SDK available for advanced custom application development
Applications Deployment: Allows various Android operation system 6.0 compliant applications to be developed, downloaded and run in the embedded device with provisioning control
QoS: Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security: User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, 128/256-bit SRTP, HTTPS, 802.1x media access control
Multi-Language English, German, Italian, French, Spanish, Portuguese, Russian, Turkish, Polish, Chinese, Korean, Japanese, and more
Upgrade/Provisioning: Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload, mass provisioning using AES encrypted XML configuration file
Power & Green Energy Efficiency Input: 100~240Vac 50/60hz; output: 12V/2A 24W
Storage Temperature: -10°C ~ +60°C
Operating Temperature: 0°C ~ +40°C
Humidity: 10% to 90% Non-condensing

Product Includes:

(1) GVC3210 Main Case

(1) Remote Control

(1) Wall Mount Bracket

(1) TV Mount Bracket

(1) Power Supply

(4) AAA Batteries

(2) Bracket Sticking Strips

(1) 1.5 m HDMI Cable

(1) 5 m HDI Cable

(1) 1.5 m Ethernet Cable

(1) Quick Installation Guide

(1) GPL License

(2) Screws
